Product information

Description

Safe, smooth and reliable elevator designed especially for hospitals, with a solid set of features for optimum performance in the highly demanding environment of patient transportation.

Specifications

  • Description: Machine room-less/ small machine room elevator for hospitals.
  • Speed: 1.75 m/s
  • Max. travel: 75 m
  • Max. load: 1768 kg
  • Max. persons: Up to 26
  • Max. group size: 4
  • Signalization: KDS90; KDS93; KDS96

Design

  • Specialized Car design to accommodate the bed and medical equipment, with wide opening doors and deeper car
  • Smooth entry and exit: precise leveling for easy entry of wheelchairs, beds and patients
  • Priority / emergency calls for immediate availability during emergency situations
  • Quiet operation to prevent disturbance to patients in wards adjacent to the elevator shaft
  • Hygiene: easy to use, durable wall and floor materials
  • Clear signalization for easy access and use

Donwload the KONE Bed Elevator brochure

Elevator solutions

Product
Description + segment
Machine room
Max. speed
Max. travel
Max. load/persons
KONE A MonoSpace®Machine-room-less elevators for low-rise residential buildingsNo
0.63 m/s20 m
544 kg / up to 8 persons
KONE A MiniSpace™
Compact Machine-room elevators for low-rise residential buildings
Yes
0.63 m/s
30 m
544 kg / up to 8 persons
KONE I MonoSpace®
Modern Elevators for Residential & Commercial buildings
No
1.75 m/s90 m
1020 kg / up to 15 persons
KONE I MiniSpaceModern Elevators for Residential & Commercial buildingsYes
1.75 m/s100 m1020 kg / up to 15 persons
KONE U MonoSpace®Machine-room-less elevators for mid range buildings
No
2.5 m/s90 m
1786 kg / up to 26 persons
KONE U MiniSpace™Compact machine room elevators for mid range buildings
Yes
2.5 m/s135 m
1786 kg / up to 26 persons
KONE Highrise MiniSpaceHigh-speed elevator for high-rise buildingsYes
4 m/s180 m
1600 kg / up to 24 persons
KONE TranSys®Adaptable passenger and goods elevator solution for public transport, retail, hospital buildings
No
1.0 m/s
40 m
4000kg / up to 53 persons
KONE Bed elevator
Elevator designed especially for hospitals
Yes & No
1.75 m/s
75 m
1768 kg / up to 26 persons
