KONE TransitMaster™ 120 Escalator

Product information

Description

The KONE TransitMaster™ 120 is a durable, eco-efficient escalator optimized for transit centers. It provides a smooth, safe ride and a pleasant passenger experience, even under the most demanding traffic conditions.

Specifications

  • Operational environment: indoor, semi-outdoor, outdoor
  • Speed: 0.5, 0.65, 0.75 m/s
  • Inclination: 27.3º, 30º, 35º
  • Step width: 800, 1000 mm
  • Vertical rise: up to 20 m

Safety

  • Safety is the starting point for every KONE solution. KONE TransitMaster™ 120 conforms to all local and international safety codes.
  • We provide standard safety features including comb plate impact device switches and emergency stop buttons for passengers.

Tools and downloads

Escalator Planner

Escalator Planner helps you select the right product as well as create detailed specifications, BIM equipment models and CAD drawings for preliminary planning.

Escalator & Autowalk Planning guide

Our easy-to-understand guide gives you all the information you need when planning an escalator or autowalk solution, including guidance on building regulations and safety codes.

TransitMaster™ 120 Escalator

Product information in a nutshell for KONE TransitMaster 120 escalator.

Specifications – Transitmaster™ 120 Escalator

Technical details and safety and design options for the KONE TransitMaster™ 120 escalator.

solutions for transit centers

Our range of solutions designed to cope with the tough demands of busy transit center environments includes elevators, escalators, autowalks, and doors.

KONE TransVario factsheet

TransVario drive - a premium escalator drive option for even better escalator performance, space-efficiency and sustainability.

Options and highlights

Travelmaster 110, 120

Energy-efficiency

  • Smart operational modes and inverter optimize energy consumption under different load conditions
  • Long lasting LED lighting is up to 80% more efficient than fluorescent lighting and lasts up to 10 times longer
  • Energy efficient inverter provides smooth speed regulation during standby operation and minimizes energy consumption at full speed
Travelmaster 110, 120

Safety enhancement

In addition to the standard safety features, we offer optional safety features including:

  • New traffic signalization solutions to provide extra guidance
  • Audible alarms provide clear guidance on escalator travel direction
  • Alarm for travel direction if passengers enter an escalator in the wrong direction
  • Fall-prevention barrier and extended balustrades provide additional passenger protection
Travelmaster 120

Design

High quality visual design for the best possible user experience:

  • Innovative and attractive lighting solutions that also improve passenger guidance and safety
  • Wide range of design options to create stunning visual effects and perfectly match your building’s architecture
  • High quality component finishes and a harmonized look and feel throughout the KONE product portfolio

Contact us for a detailed cost estimate

Related topics

Escalator and autowalk solutions

Product name
Description (+type)
Segment
Maximum rise
Speed
Inclination
Duty cycle
Environment
TravelMaster 110
EscalatorCommercial, retail, hotel, office
13 m
0.4, 0.5 m/s
30°, 35°
12-16 hours/day
Indoor, outdoor, semi-outdoor
TravelMaster 115
Inclined AutowalkCommercial, retail, hotel, office
7 m
0.5 m/s
10°, 12°
12-16 hours/day
Indoor, semi-outdoor
TransitMaster 120
EscalatorInfrastructure
15 m
0.4, 0.5, 0.65, 0.75 m/s27.3°, 30°, 35°20 hours/dayIndoor, semi-outdoor, outdoor
TransitMaster 140
EscalatorInfrastructure
18 m
0.4, 0.5, 0.65, 0.75 m/s27.3°, 30°20-24 hours/dayIndoor, outdoor
TransitMaster 165
Horizontal AutowalkInfrastructure
15-60 m
0.4, 0.5, 0.65, 0.75 m/s
0-6°
20-24 hours/day
Indoor, semi-outdoor
TransitMaster 185
Horizontal AutowalkInfrastructure
15-100 m
0.4, 0.5, 0.65, 0.75 m/s
0-6°
20-24 hours/day
Indoor, semi-outdoor
